Specifications

• ENGINE

  add remove
  • Engine Type:
    V Twin
  • Cylinders:
    2
  • Engine Stroke:
    4-Stroke
  • Torque (Ft Lbs):
    82
  • Torque (Nm):
    110
  • Valves:
    4
  • Valve Configuration:
    OHV - Pushrod
  • Bore (in):
    4.094
  • Stroke (in):
    2.9
  • Displacement (cc):
    1250
  • Compression Ratio:
    12.5:1
  • Torque RPM:
    6300
  • Fuel Injector Size (mm):
    60
  • Horsepower (bhp):
    105
• TRANSMISSION

  add remove
  • Number Of Speeds:
    6
  • Gear Ratio (1):
    2.769
  • Gear Ratio (2):
    1.882
  • Gear Ratio (3):
    1.5
  • Gear Ratio (4):
    1.273
  • Gear Ratio (5):
    1.125
  • Gear Ratio (6):
    0.966
  • Final Drive Ratio:
    2.276
• TECHNICAL SPECIFICATIONS

  add remove
  • Length (in):
    86.9
  • Width (in):
    36.6
  • Height (in):
    42.2
  • Wheelbase (in):
    61.5
  • Dry Weight (lbs):
    522
  • Wet Weight (lbs):
    542
  • GVWR (lbs):
    988
  • Fuel Capacity (gal):
    3.4
  • Engine Displacement to Weight (cc):
    2.39
  • Ground Clearance (in):
    4.3
• WHEELS & TIRES

  add remove
  • Front Tire (Full Spec):
    Pirelli® MT60RS: 130/90B16 67H
  • Rear Tire (Full Spec):
    Pirelli® MT60RS: 150/80B16 77H
